Energy Storage Integrated Cabinet Series XPI-100kw215kwh IP54 Air-cooled Liquid-cooled

Name: Energy Storage Integrated Cabinet Series XPI-100kw215kwh IP54 Air-cooled Liquid-cooled
Brand: Wenzhou Esperidin Import and Export Co., Ltd
SKU: XPI-100kw215kwh
Price: 5.00 USD
Availability: InStock

Product Details

Place of Origin: China

Certification: CE、MSDS

Model Number: XPI-100kw215kwh

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Packaging Details: 1500×2306×1539mm-1350×2050×1350mm

Delivery Time: 5-8 weeks

Payment Terms: L/C,D/A,D/P,T/T

Supply Ability: 1000 pcs per mouth

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Communication Protocol:	Ethernet/RS485/CAN	Net Weight:	2500-3500kg
Protection Class:	IP54	Cooling Method:	Air-cooled / Liquid-cooled
Cycle Life:	6,000 Cycles	Certification:	CE/UN38.3/RoHS
Maximum DC Current:	140A	Storage Temperature:	-20～55℃

Communication Protocol:	Ethernet/RS485/CAN
Net Weight:	2500-3500kg
Protection Class:	IP54
Cooling Method:	Air-cooled / Liquid-cooled
Cycle Life:	6,000 Cycles
Certification:	CE/UN38.3/RoHS
Maximum DC Current:	140A
Storage Temperature:	-20～55℃

Description

Energy Storage Integrated Cabinet Series XPI-100kw215kwh IP54 Air-cooled Liquid-cooled

Energy Storage Integrated Cabinet Series XPI-100kw215kwh IP54 Air-cooled Liquid-cooled

Product parameter

Model		XPI - 100kW215kWh	XPI - 100kW232kWh
Battery Pack Parameters
Battery Pack Model		768V280Ah	832V280Ah
Rated Energy		215.04kWh	232kWh
Operating Voltage Range		672～864V	728～936V
BMS Communication Protocol		Ethernet/RS485/CAN	Ethernet/RS485/CAN
Energy Storage Converter Parameters
Grid - side Parameters	Rated AC Power	100kW
	Maximum AC Power	100kW
	Maximum AC Current	150A
	Rated Grid Voltage	380V
	Rated Grid Frequency	50/60Hz
DC - side Parameters	Maximum Input Voltage	950V	936V
	Maximum DC Current	140A
	Battery Bank Voltage Range	650～950V	728～936V
MPPT Parameters
Low - voltage Side	Rated Power	100kW	100kW
	Rated Current	320A	320A
	MPPT Voltage Range	200～650V (320～650V full - load)	200～650V (320～650V full - load)
High - voltage Side	Rated Power	100kW	100kW
	Rated Current	100A	100A
	Voltage Working Range	350～1000V	350～1000V
General Parameters
Energy Storage Cabinet Size		1500×2306×1539mm	1350×2050×1350mm
IP Rating		IP54
Operating Temperature		-20～55℃
Cooling Method		Air - cooled	Liquid - cooled
Certification		CE/UN38.3/RoHS
Product Net Weight		3500kg	2500kg
